Single Cylinder Compressor
WBS No. CW.131.001
Product overview
Single Cylinder Compressor
Technical specifications
| Brand | MERCEDES-BENZ |
|---|---|
| Cylinder Diameter | Ø85 mm |
| Volume | 352 cm³ |
| Piston Operating Distance | 62 mm |
| Port 0 | M30x1.5 |
| Port 2 | M26x1.5 |
| Port 4 | M12x1.5 |
| Port 8.1 | Ø4 mm |
| Port 8.2 | Ø15.5 mm |
| Port 9 | M12x1.5 |
| Port 9.1 | M16x1.5 |
| Port 9.2 | M16x1.5 |
| Crankshaft Thread | M20x1.5 LH |
| Number of Cylinders | 1 |
| Cooling | Water |
| With ESS Feature | YES |
| Water Cooled Valve Plate | YES |
| Direct Working | Yes |
| Maximum Operating Pressure | 12.5 bar |
| Weight | 14.7 kg |
Reference numbers
Confirm the reference and application with WBS before ordering.
Wabco
412 352 026 0 · 412 352 007 0 · 412 352 010 0 · 412 352 006 0 · 412 352 017 0 · 412 352 014 0
Mercedes-Benz
A 457 130 44 15 · 457 130 44 15 · A 457 130 24 15 · 457 130 24 15 · A 457 130 67 15 · A 457 130 11 15 · 457 130 11 15 · 457 130 17 15 · A 457 130 08 15 · 457 130 08 15 · 906 130 08 15 · A 457 130 17 15 · 906 130 17 15
Daimler
A 457 130 67 15
Product Code
CW.131.001
Vehicles Used
| Mercedes-Benz |
|---|
